NORD ONE NC500
-
Nord One NC5003CH MKII 3 Channel Power Amplifier
£1,799.00SPECIFICATION
• Standard Stereo Case
• 3 x Hypex NCore NCx500 Module
• 3 x Hypex SMPS1200A700 Power Supply
• 3 x Nord REV D Input Buffer Board Choice of Op Amps.
• Distortion: THD+N – – 0.001 % 20Hz
• Frequency Response: 0 – 50k Hz +0/-3dB
• Low Distortion: THD+N – – 0.001 % 20Hz
• High Input Impedance 47K
• 26 dB Gain
• Ultra High Damping Factor
• High 28A Current Output Capable of driving 2ohm for the
Most Demanding of Speakers.
550W 2ohm
700W 4ohm
400W 8ohm
• Frequency Response: 0 – 50k Hz +0/-3dB
• Case mm W 450 D 365 H 100
• Weight 12.5Kg
-
Nord One NC500DM MKII Dual Mono Stereo Power Amplifier
£1,379.00• Standard Stereo Case (Optional High Quality SE case)
• 2 x Hypex NCore NC500 Module
• 2 x Hypex SMPS1200A700 Power Supply
• 2 x Nord REV D Input Buffer Board Choice of Op Amps.
• Distortion: THD+N – – 0.001 % 20Hz
• Frequency Response: 0 – 50k Hz +0/-3dB
• Low Distortion: THD+N – – 0.001 % 20Hz
• High Input Impedance 47K
• 26 dB Gain
• Ultra High Damping Factor
• High Current Output Capable of driving 2ohm for the
Most Demanding of Speakers.
550W 2ohm
700W 4ohm
400W 8ohm
• Frequency Response: 0 – 50k Hz +0/-3dB
• Case mm W 450 D 365 H 102 SE Case W 430 D 330 H 100
• Weight 9Kg
-
Nord One NCx5003CH MKII 3 Channel Power Amplifier
£1,949.00SPECIFICATIONS (Per Channel)
• Standard 3CH Case
• 3 x Hypex NCore NCx500 Module
• 3 x Hypex SMPS1200A700 Power Supply
• 3 x Nord REV D Input Buffer Board Choice of Op Amps.
• Distortion: THD+N – – 0.001 % 20Hz
• Frequency Response: 0 – 50k Hz +0/-3dB
• Low Distortion: THD+N – – 0.001 % 20Hz
• High Input Impedance 47K
• 26 dB Gain
• Ultra High Damping Factor
• High 28A Current Output Capable of driving 2ohm for the
Most Demanding of Speakers.
700W 2ohm
700W 4ohm
380W 8ohm
• Frequency Response: 0 – 50k Hz +0/-3dB
• Case mm W 450 D 365 H 100
• Weight 12.5Kg
-
Nord One NCx500DM MKII Dual Mono Stereo Power Amplifier
£1,479.00SPECIFICATION
• Standard Stereo Case (Optional High Quality SE case)
• 2 x Hypex NCore NCx500 Module
• 2 x Hypex SMPS1200A700 Power Supply
• 2 x Nord REV D Input Buffer Board Choice of Op Amps.
• Distortion: THD+N – – 0.001 % 20Hz
• Frequency Response: 0 – 50k Hz +0/-3dB
• Low Distortion: THD+N – – 0.001 % 20Hz
• High Input Impedance 47K
• 26.8 dB Gain
• Ultra High Damping Factor
• High 28A Current Output Capable of driving 2ohm for the
Most Demanding of Speakers.
700W 2ohm
700W 4ohm
380W 8ohm
• Frequency Response: 0 – 50k Hz +0/-3dB
• Case mm W 450 D 365 H 102 SE Case W 430 D 330 H 100
• Weight 9Kg
-
Nord One NCx500MB MKII Mono Block Power Amplifier
£870.00SPECIFICATION
• Standard Mono Block Case (Optional SE case)
• 1 x Hypex NCore NCx500 Module
• 1 x Hypex SMPS1200A700 Power Supply
• 1 x Nord REV D Input Buffer Board Choice of Op Amps.
• Distortion: THD+N – – 0.001 % 20Hz
• Frequency Response: 0 – 50k Hz +0/-3dB
• Low Distortion: THD+N – – 0.001 % 20Hz
• High Input Impedance 47K
• 26.8 dB Gain
• Ultra High Damping Factor
• High 28A Current Output Capable of driving 2ohm for the
Most Demanding of Speakers.
700W 2ohm
700W 4ohm
380W 8ohm
• Frequency Response: 0 – 50k Hz +0/-3dB
• Case mm W 240 D 280 H 100 SE Case W 280 D 230 H 100
• Weight 4.5Kg
-
Nord One NCx500ST Stereo Power Amplifier
£1,079.00SPECIFICATION
• Standard Stereo Case (Optional SE Case)
• 2 x Hypex NCore NCx500 Module
• 1 x Hypex SMPS1200A700 Power Supply
• 2 x Nord NCx Input connection board
• Distortion: THD+N – – 0.001 % 20Hz
• Frequency Response: 0 – 50k Hz +0/-3dB
• Low Distortion: THD+N – – 0.001 % 20Hz
• High Input Impedance 47K
• 26.8 dB Gain
• Ultra High Damping Factor
• High 28A Current Output Capable of driving 2ohm for the
Most Demanding of Speakers.
700W 2ohm
700W 4ohm
380W 8ohm
• Frequency Response: 0 – 50k Hz +0/-3dB
• Case mm W 450 D 405 H 102 SE Case W 430 D 330 H 100
• Weight 9Kg
